ALUMINUM Z-SHAPED PROFILES
Omar srl manufactures and sells aluminum Z-profiles. SALES AND DELIVERIES are usually prompt, even for small quantities. The aluminum profiles are cut and machined. We supply Z-profiles in ENAW6060 aluminum alloy.
Commercial length of the bars: 6 m
| 'Z' PROFILES | A | B | C | S | GR/MT |
|---|---|---|---|---|---|
| Z 4x4x16x1 | 4 | 4 | 16 | 1 | 59 |
| Z 4x4x22x1 | 4 | 4 | 22 | 1 | 76 |
| Z 4x11x7x1 | 4 | 11 | 7 | 1 | 54 |
| Z 4,5x4,5x12x1 | 4,5 | 4,5 | 12 | 1 | 51 |
| Z10x10x15x2 | 10 | 10 | 15 | 2 | 167 |
| Z 10x10x20x1,5 | 10 | 10 | 20 | 1,5 | 150 |
| Z 10x10x20x2 | 10 | 10 | 20 | 2 | 194 |
| Z 10x10x25x1,5 | 10 | 10 | 25 | 1,5 | 170 |
| Z 10x10x25x2 | 10 | 10 | 25 | 2 | 221 |
| Z 10x10x30x1,5 | 10 | 10 | 30 | 1,5 | 190 |
| Z 10x10x30x2 | 10 | 10 | 30 | 2 | 248 |
| Z 10x90x20x2 | 10 | 90 | 20 | 2 | 626 |
| Z 11x11x6x2 | 11 | 11 | 6 | 2 | 130 |
| Z 11x11x10x2 | 11 | 11 | 10 | 2 | 151 |
| Z 11x16,5x13x2,3 | 11 | 16,5 | 13 | 2,3 | 237 |
| Z 12x20x10x3 | 12 | 20 | 10 | 3 | 291 |
| Z 12x25x15x2 | 12 | 25 | 15 | 2 | 260 |
| Z 12x30x20x1,5 | 12 | 30 | 20 | 1,5 | 239 |
| Z 14x14x18x4 | 14 | 14 | 18 | 4 | 411 |
| Z 15x12x25x2 | 15 | 12 | 25 | 2 | 265 |
| Z 15x15x19x3 | 15 | 15 | 19 | 3 | 348 |
| Z 15x15x20x3 | 15 | 15 | 20 | 3 | 356 |
| Z 15x15x25x2 | 15 | 15 | 25 | 2 | 275 |
| Z 15x15x30x2 | 15 | 15 | 30 | 2 | 302 |
| Z 15x15x35x3 | 15 | 15 | 35 | 3 | 478 |
| Z 15x20x15x2 | 15 | 20 | 15 | 2 | 249 |
| Z 15x25x15x3 | 15 | 25 | 15 | 3 | 397 |
| Z 15x33x20x2 | 15 | 33 | 20 | 2 | 345 |
| Z 15x45x15x2 | 15 | 45 | 15 | 2 | 383 |
| Z 15x50x15x1,5 | 15 | 50 | 15 | 1,5 | 313 |
| Z 16x16x15x2 | 16 | 16 | 15 | 2 | 232 |
| Z 17x25x17x2 | 17 | 25 | 17 | 2 | 297 |
| Z 17x32x17x2 | 17 | 32 | 17 | 2 | 335 |
| Z 18x20x21x3 | 18 | 20 | 21 | 3 | 430 |
| Z 20x12x10x3 | 20 | 12 | 10 | 3 | 291 |
| Z 20x15x20x1,5 | 20 | 15 | 20 | 1,5 | 211 |
| Z 20x15x20x3 | 20 | 15 | 20 | 3 | 397 |
| Z 20x18x21x3 | 20 | 18 | 21 | 3 | 429 |
| Z 20x20x20x2 | 20 | 20 | 20 | 2 | 302 |
| Z 20x20x20x3 | 20 | 20 | 20 | 3 | 437 |
| Z 20x30x20x3 | 20 | 30 | 20 | 3 | 518 |
| Z 25x15x12x2 | 25 | 15 | 12 | 2 | 400 |
| Z 25x25x25x2 | 25 | 25 | 25 | 2 | 400 |
| Z 25x25x25x3 | 25 | 25 | 25 | 3 | 559 |
| Z 25x29x25x2 | 25 | 29 | 25 | 2 | 405 |
| Z 25x40x25x3 | 25 | 40 | 25 | 3 | 680 |
| Z 25x40x50x3 | 25 | 40 | 50 | 3 | 883 |
| Z 25x50x25x2 | 25 | 50 | 25 | 2 | 519 |
| Z 30x30x30x2 | 30 | 30 | 30 | 2 | 464 |
| Z 30x30x30x3 | 30 | 30 | 30 | 3 | 680 |
| Z 30x40x30x3 | 30 | 40 | 30 | 3 | 761 |
| Z 30x50x30x3 | 30 | 50 | 30 | 3 | 842 |
| Z 30x86x30x3 | 30 | 86 | 30 | 3 | 1135 |
| Z 35x40x35x3 | 35 | 40 | 35 | 3 | 842 |
| Z 35x45x35x3 | 35 | 45 | 35 | 3 | 887 |
| Z 36x45x36x3 | 36 | 45 | 36 | 3 | 899 |
| Z 40x30x40x4 | 40 | 30 | 40 | 4 | 1102 |
| Z 40x40x25x3 | 40 | 40 | 25 | 3 | 802 |
| Z 40x40x40x3 | 40 | 40 | 40 | 3 | 924 |
| Z 40x40x40x4 | 40 | 40 | 40 | 4 | 1210 |
| Z 40x46,5x46,5x2,5 | 40 | 46,5 | 46,5 | 2,5 | 864 |
| Z 40x60x40x2 | 40 | 60 | 40 | 2 | 734 |
| Z 40x65x40x4 | 40 | 65 | 40 | 4 | 1480 |
| Z 40x70x40x3 | 40 | 70 | 40 | 3 | 1166 |
| Z 40x86x40x3 | 40 | 86 | 40 | 3 | 1190 |
| Z 50x50x50x5 | 50 | 50 | 50 | 5 | 1890 |
| Z 50x51x50x1,5 | 50 | 51 | 50 | 1,5 | 600 |
| Z 64x15x2 | 64 | 15 | 2 | 800 |
