Catalogue, handbook Semicircular aluminum tubes

Omar srl production and sale of aluminum profiles with section: semicircular aluminum tubular sections. SALE AND DELIVERY IN prompt delivery even for modest quantities. We carry out cutting operations and mechanical machining on aluminum profiles. We supply ENAW6060 aluminum alloy rectangular tubes

Complete range of our aluminum profiles available on the website: www.omar-alluminio.it

Catalog Measurements of rectangular pipes with sharp edges

Catalog of square pipe sizes with sharp edges

Round tube sizes catalogue

Catalog Measurements of rectangular tubes with radiused edges

Catalog of square tube sizes with rounded edges

Catalog of semicircular tube sizes

SEMICIRCULAR TUBES	A	B	S	GR/MT
TS 12,6x8,3x2	12,6	8,3	2	153
TS 14,8x9,4x2	14,8	9,4	2	184
TS 20x10x1,5	20	10	1,5	195
TS 20x15x1	20	15	1	143
TS 20,5x13x2,75	20,5	13	2,75	350
TS 22x12x1,4	22	12	1,4	164
TS 22x12x2	22	12	2	278
TS 22,5x15,25x1,6	22,5	15,25	1,6	247
TS 23x15x1,5	23	15	1,5	237
TS 24,2x11,6x1,2	24,2	11,6	1,2	187
TS 24,6x14,6x1,8	24,6	14,6	1,8	322
TS 25x10x1,2	25	10	1,2	186
TS 25x10x1,5	25	10	1,5	229
TS 25x10x1,8	25	10	1,8	270
TS 26x6x1,5	26	6	1,5	218
TS 26x14,5x2	26	14,5	2	395
TS 26x16x1	26	16	1	184
TS 26x16x1,5	26	16	1,5	265
TS 26x16x2	26	16	2	345
TS 29x19X1	29	19	1	207
TS 29,3x17,5x1,5	29,3	17,5	1,5	299
TS 30x7,7x1,6	30	7,7	1,6	275
TS 30x14,5x1,7	30	14,5	1,7	326
TS 30x15x1,2	30	15	1,2	238
TS 30x15x1,5	30	15	1,5	293
TS 30x15x2	30	15	2	382
TS 30x16x2	30	16	2	388
TS 30x18x1,5	30	18	1,5	305
TS 30x18x2	30	18	2	395
TS 30x18,5x2,25	30	18,5	2,25	451
TS 30x19x1,5	30	19	1,5	312
TS 30x19x2,2	30	19	2,2	445
TS 30x19x4	30	19	4	747
TS 31x13,1x1,5	31	13,1	1,5	286
TS 31x21x2	31	21	2	432
TS 32x21,6x2,3	32	21,6	2,3	540
TS 32x21,6x2,5	32	21,6	2,5	545
TS 32x24x3	32	24	3	664
TS 34,6x24,6x2,3	34,6	24,6	2,3	559
TS 35x18x2	35	18	2	455
TS 35x20x1,5	35	20	1,5	356
TS 35x20,2x1,6	35	20,2	1,6	380
TS 36x18x1,5	36	18	1,5	350
TS 36x18x2	36	18	2	505
TS 36x18x2,5	36	18	2,5	530
TS 38x10x1	38	10	1	227
TS 38x20x2	38	20	2	500
TS 40x10x1	40	10	1	238
TS 40x20x1,4	40	20	1,4	373
TS 40x20x1,5	40	20	1,5	397
TS 40x20x2	40	20	2	521
TS 40x20x3	40	20	3	757
TS 41,8x22x1,5	41,8	22	1,5	419
TS 42x22x1,5	42	22	1,5	424
TS 42x22x2,5	42	22	2,5	683
TS 43,4x18,4x2,5	43,4	18,4	2,5	672
TS 43,7x8,8x1,2	43,7	8,8	1,2	306
TS 44x20x1,5	44	20	1,5	432
TS 44,5x7,8x1,1	44,5	7,8	1,1	278
TS 45x8x1,2	45	8	1,2	~270
TS 45x15x2	45	15	2	556
TS 45x18x1,8	45	18	1,8	511
TS 45x23x2	45	23	2	594
TS 48x22x2	48	22	2	621
TS 49,5x9,95x1,1	49,5	9,95	1,1	315
TS 50x8x1	50	8	1	286
TS 50x9x1,4	50	9	1,4	391
TS 50x10x0,9	50	10	0,9	280
TS 50x10x0,95	50	10	0,95	265
TS 50x10x1	50	10	1	292
TS 50x10x1,1	50	10	1,1	327
TS 50x10x1,2	50	10	1,2	348
TS 50x10x1,25	50	10	1,25	363
TS 50x10x1,3	50	10	1,3	378
TS 50x10x1,40	50	10	1,4	405
TS 50x20x1,35	50	20	1,35	432
TS 50x20x1,5	50	20	1,5	478
TS 50x20x2	50	20	2	629
TS 50x20x3	50	20	3	920
TS 50x25x1,75	50	25	1,75	581
TS 50x25x2	50	25	2	660
TS 50x25x2,5	50	25	2,5	810
TS 50x25x3	50	25	3	964
TS 50x25x4	50	25	4	1252
TS 50x30x1,5	50	30	1,5	525
TS 50x30x2	50	30	2	691
TS 50,1x10,1x1,45	50,1	10,1	1,45	419
TS 52x26x1,4	52	26	1,4	489
TS 59,5x38,5x8,5	59,5	38,5	8,5	3124
TS 60x10x1	60	10	1	346
TS 60x10x1,1	60	10	1,1	380
TS 60x10x1,2	60	10	1,2	413
TS 60x10x1,3	60	10	1,3	449
TS 62x12x1,2	62	12	1,2	435
TS 65x10x1	65	10	1	373
TS 65x10x1,1	65	10	1,1	420
TS 65x10x1,25	65	10	1,25	464
TS 65x10x1,3	65	10	1,3	481
TS 65x20x1,5	65	20	1,5	603
TS 70x27x2	70	27	2	889
TS 70x40x2	70	40	2	970
TS 70x40x5	70	40	5	2294
TS 74,9x64,9x1,7	74,9	64,9	1,7	1003
TS 77x22x1,5	77	22	1,5	706
TS 80x15x1,8	80	15	1,8	833
TS 80x40x4	80	40	4	2084
TS 90x36x2	90	36	2	1158
TS 100x40x4	100	40	4	2516
TS 110x26x3	110	26	3	1945
TS 120x33x1,8	120	33	1,8	1322
TS 160x80x3	160	80	3	3255
TS 180x55x2,5	180	55	2,5	2801
TS 181x111,5x3,5	181	111,5	3,5	4527
TS 260x100x10	260	100	10	16270

Rectangular aluminum tubes

Rectangular tube catalogue

Tubular aluminum profiles: rectangular, box-shaped aluminum tubes, even of large dimensions and with large thicknesses. Where not otherwise specified, the aluminum alloy used is according to the UNI standard: EN-AW6060

Square aluminum tubes

Square tube catalogue

Square tube aluminum profiles: extruded square tubular box profiles, even of large dimensions. Where not otherwise specified, the aluminum alloy used according to the UNI standard: EN-AW6060

Rectangular tubes with rounded edges in aluminium

Radius rectangular tubes catalogue

Rectangular tubular aluminum profiles with radiused / rounded corners: rectangular box-shaped tubular extruded profiles with radius also of large dimensions. Where not otherwise specified, the aluminum alloy used is according to the UNI: ENAW6060 standard

Square tubes with rounded edges in aluminium

Catalog of square tubes with radiused edges

Aluminum profiles, square tubes with radiused/rounded corners, even in large dimensions. Where not otherwise specified, the aluminum alloy used is according to the UNI standard: EN-AW6060

Semicircular aluminum tubes

Semicircular tube catalogue

Semi-circular aluminum tubular profiles: we have a wide range of semi-circular aluminum tubular profiles. Where not otherwise specified, the aluminum alloy used is according to the UNI standard: ENAW6060

Round aluminum tubes

Round tube catalogue

Round tube aluminum profiles ready for delivery: bars of round tubes in extruded aluminium, including large ones. Where not otherwise specified, the aluminum alloy used is according to the UNI standard: EN-AW6060

Standard aluminum profiles

Standard profile catalogue

Production and sale of standard / commercial aluminum profiles available in stock in bars usually measuring 6 m. Where not otherwise specified, the aluminum alloy used is according to the UNI standard: EN-AW6060

Special aluminum profiles

Aluminum profiles catalogue

Wide range of aluminum profiles of various shapes and sizes, we can supply these profiles in bar form or cut to size and machined to a design and possibly anodized.

Further types of aluminum profiles:

Trade and sale of ALUMINUM PROFILES THROUGHOUT ITALY even for modest quantities, for:

Aluminum containers for electronic cards

Extruded aluminum profiles for screen printing squeegee holders

PDF catalog of special profiles (nails, glazing beads, edging, joint covers, frames, handrails, handles, drainers, water guards, fenders, corner guards, stair nosings, runners, sign holders, price holders etc..)

We carry out mechanical processes such as:

Cutting to size on aluminum profiles, even large ones, drilling, threading, milling, shearing and finishes such as anodizing, painting on aluminum profiles even for modest quantities
